產品介紹

Temperature measurement range

-20℃ to +600℃

Accuracy

±2℃ or 2％

Field of View

23o×17o

Spatial resolution (IFOV)

1.25 mRad

Minimum focus distance

Thermal lens：15cm
Visible light lens：46cm

Image frequency

9 Hz refresh rate

Detector type

320 X 240 Focal Plane Array,
uncooled microbolometer

Infrared spectral band

7.5 μm to 14 μm (long wave)

Thermal sensitivity (NETD)

≤ 0.045 degrees C and 45 mK

Visual camera

Industrial performance 2.0 megapixel

Optional telephoto infrared lens type

Field of view : 11.5 ° x 8.7 °
Spatial resolution (IFOV) : 0.63 mRad
Minimum focus distance : 45 cm (approx. 18 in)

IP rating

IP54
